LLR-M18PA-NMK-101

Operating range 0...25000 mm
Switching frequency max. 1000 Hz
Supply voltage 10...30
Polarity NPN
Output Light-on + Dark-on
Sensitivity adjustment No
Connection PVC, 2 m, 4 wire
Housing size [mm] M18
Enclosure rating IP 67
Housing material ABS
Temperature range -25...+65°C
Light source LED, red 630 nm
Interface Standard output
Operating principle Through-beam
Sensing range max. 0...30000 mm
Type Format
Datasheet pdf
Operating manual pdf
CE certificate pdf
UKCA certificate pdf
UL certificate pdf
Photoelectrics Sensor Standard-Through-beam-M18-025000-mm-ABS-No-LED-red-630-nm LLR-M18PA-NMK-101

Standard Through beam M18 0...25000 mm ABS No LED, red 630 nm

SKU: LLR-M18PA-NMK-101

Connection: PVC, 2 m, 4 wire
Output: Light-on + Dark-on
Polarity: NPN
PVC, 2 m, 4 wire ! Light-on + Dark-on ! NPN
PVC, 2 m, 4 wire ! Dark-on + Stability alarm ! NPN
PVC, 2 m, 3 wire ! Dark-on ! NPN
PVC, 2 m, 3 wire ! IO-Link ! Emitter
PVC, 2 m, 3 wire ! Dark-on/IO-Link ! PNP
PVC, 2 m, 4 wire ! Light-on/IO-Link + Dark-on ! PNP
PVC, 2 m, 4 wire ! Dark-on/IO-Link + Stability alarm ! PNP
M12 4-pin ! Light-on + Dark-on ! NPN
M12 4-pin ! Dark-on + Stability alarm ! NPN
M12 4-pin ! Dark-on ! NPN
M12 4-pin ! IO-Link ! Emitter
M12 4-pin ! Dark-on/IO-Link ! PNP
M12 4-pin ! Light-on/IO-Link + Dark-on ! PNP
M12 4-pin ! Dark-on/IO-Link + Stability alarm ! PNP
