Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2 Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2 Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2 Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2 Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2 Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2 Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2 Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2 Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2 Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2 Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2 Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2 Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2 Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2 Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2 Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2 Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2 Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2 Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2 Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2 Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2 Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2 Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2 Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2
Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2 Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2

TRU-C23PA-TMK-101

Operating range 0...1000 mm
Switching frequency max. 1000 Hz
Supply voltage 15...30
Polarity NPN
Output Light-on + Dark-on
Sensitivity adjustment Teach button
Connection PVC, 2 m, 4 wire
Housing size [mm] 20 x 30 (C23)
Enclosure rating IP 67
Housing material ABS
Sensitivity Range Adjustment 30...5000 mm
Temperature range -25...+65°C
Light source LED, UV 275 nm, Risk Group 2
Interface Standard output
Operating principle Transparent reflex
Sensing range max. 0...1200 mm
Type Format
Datasheet pdf
Operating manual pdf
CE certificate pdf
UKCA certificate pdf
UL certificate pdf
Photoelectrics Sensor Transparent-object-Transparent-reflex-20-30-C23-01000-mm-ABS-Teach-button-LED-UV-275-nm-Risk-Group-2 TRU-C23PA-TMK-101

Transparent object Transparent reflex 20 x 30 (C23) 0...1000 mm ABS Teach button LED, UV 275 nm, Risk Group 2

SKU: TRU-C23PA-TMK-101

Connection: PVC, 2 m, 4 wire
Output: Light-on + Dark-on
Polarity: NPN
PVC, 2 m, 4 wire ! Light-on + Dark-on ! NPN
PVC, 2 m, 4 wire ! Dark-on + Stability alarm ! NPN
PVC, 2 m, 4 wire ! Light-on/IO-Link + Dark-on ! PNP
PVC, 2 m, 4 wire ! Dark-on/IO-Link + Stability alarm ! PNP
M8 4-pin ! Light-on + Dark-on ! NPN
M8 4-pin ! Dark-on + Stability alarm ! NPN
M8 4-pin ! Light-on/IO-Link + Dark-on ! PNP
M8 4-pin ! Dark-on/IO-Link + Stability alarm ! PNP
Regular price RM890.00 MYR
In stock
secure icon

Secure Checkout

  • American Express
  • Apple Pay
  • Google Pay
  • Mastercard
  • Shop Pay
  • Union Pay
  • Visa
Contact Icon

Need help? Click here to contact an expert

TRU-C23PA-TMK-101

Operating range 0...1000 mm
Switching frequency max. 1000 Hz
Supply voltage 15...30
Polarity NPN
Output Light-on + Dark-on
Sensitivity adjustment Teach button
Connection PVC, 2 m, 4 wire
Housing size [mm] 20 x 30 (C23)
Enclosure rating IP 67
Housing material ABS
Sensitivity Range Adjustment 30...5000 mm
Temperature range -25...+65°C
Light source LED, UV 275 nm, Risk Group 2
Interface Standard output
Operating principle Transparent reflex
Sensing range max. 0...1200 mm
Type Format
Datasheet pdf
Operating manual pdf
CE certificate pdf
UKCA certificate pdf
UL certificate pdf
Photoelectrics Sensor Transparent-object-Transparent-reflex-20-30-C23-01000-mm-ABS-Teach-button-LED-UV-275-nm-Risk-Group-2 TRU-C23PA-TMK-101
